Raymarine CPT-S Transducer – simple, reliable and accurate transducer for CHIRP sonar
Raymarine CPT-S It's compact and affordable flush-mounted sonar transducer, which offers quality CHIRP sonar imaging and precise depth data display. Thanks to its simple design, the CPT-S is quick and easy to install and is ideally suited for outboard motorboats.
Main features:
-
Supports single-channel High CHIRP sonar 25° conical quick-release
-
Built-in seawater temperature sensor
-
Scope up to 274 metres (900 feet)
-
In a set 10-metre cable and mounting bracket
-
Superb performance even at high speeds
Compatibility with Raymarine chartplotters:
Element S
CPT-S connector attaches directly Element S with a series of plotters.
Axiom Pro S and Axiom 2 Pro S
Recommended sensor for these models. Required A80490 adapter cable, to connect the CPT-S sensor to the device.
Element HV
To connect the CPT-S to the Element HV plotter, you will need A80559 adapter lead.
Please note! CPT-S only supports High CHIRP sonar. HyperVision sonar requires an HV series transducer.
Axiom series with sonar models
Connects directly Axiom DV with the transducer. Required for use with other Axiom devices with sonar functionality A80490 adapter cable.
NB! CPT-S only supports High CHIRP sonar.
Raymarine CPT-S is a reliable sonar solution for those seeking simplicity, accuracy, and quality. CHIRP technology for a small vessel or boat. Ideal for both the amateur and the experienced captain.
